New High-resolution Ampire AM-19201080F1TZQW-A0 15.6 inch TFT Displays for Industrial Use

Short Description:

The AM-19201080F1TZQW-A0 is a 15.6″ TFT display with Full HD resolution,each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical Stripe and this module can display 16.7M colors and has a brightness of 1000cd/m² for a brilliant image display.

Based on its features, recommend that this model be applied to Industrial, Outdoor High Brightness etc.

CONTACT NOW

Product Detail

Product Tags

Parameters:

Brand	Ampire	Model P/N	AM-19201080F1TZQW-A0
Diagonal Size	15.6''	Product Series	TFT Displays
Resolution	1920x1080	Technology	TFT
Active Area	344.16x193.59mm	Backlight	LED
Outline Dim.	363.8x215.9x13.28mm	Interface	LVDS (2ch)
Luminance	1000cd/m²	Contrast Ratio	800:1
Display Colors	16.7M	Response Time	35ms
Operation Temperature	-30 ~ 75°C	Storage Temperature	-30 ~ 80°C

Product Characteristics:

1.3.3V Logic Power
2.Life ≥ 50K hours
3.16.7M Colors (6bit + HFRC)
4.On board LED Driving circuit
5.Green Product (RoHS)
6.Ultra High Brightness

Product Features:

1.Physical characteristics: can withstand the adverse environmental impact,with dustproof, waterproof and anti-interference function, with strong anti-interference ability.

2.High Stability: adopts industrial-grade core devices, which are not easy to fail, and spare parts are easy to maintain, and can achieve 7*24 hours non-stop work.

3.Ease of use: The human-computer interface of the industrial control screen is intuitive and friendly, easy to operate.

4.Scalability: I/O modules and protocols can be added according to user requirements to meet different application requirements.

5.Various Applications: be widely used in automation equipment, robots, assembly lines, logistics systems and other production and manufacturing fields, as well as sewage treatment, ships, offshore wind power and other transportation fields, and even petrochemical, coal mining, printing, electricity and other production and manufacturing fields.
