46inch P460HVN03.0 1920x1080 industrial grade LCD screen
Product Features:
AUO 46'' TFT display P460HVN03.0 includes the LED backlight driving board and features a very wide viewing angle.
Parameters:
Application:
Based on its features, Headsun recommend that this model be applied to Digital Signage, Kiosk, advertising display, industrial machine etc.
AUO 46'' TFT display P460HVN03.0 includes the LED backlight driving board and features a very wide viewing angle.
Parameters:
| Brand | AUO | Model P/N | P460HVN03.0 |
| Diagonal Size | 46.0" | Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920x1080 | Pixel Format | RGB Vertical Stripe |
| Active Area | 1018.08x572.67mm | Treatment | Antiglare |
| Outline Dim. | 1044.08x598.67x28.5mm | Contrast Ratio | 4000:1 (Typ.) (TM) |
| Luminance | 700 cd/m² (Typ.) | Response Time | 8 (Typ.)(G to G) |
| View Direction | Symmetry | Operating Mode | IPS, Normally Black, Transmissive |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Light Source | WLED , With LED Driver |
| Support Color | 1.07B 94% DCI-P3 | Touch Panel | Without |
| Good View at | 11.6Kgs (Typ./Max.) | ||
| Frame Rate | 60Hz | ||
| Interface Type | LVDS (2 ch, 8/10-bit) , 51 pins Connector | ||
| Power Supply | 12.0V (Typ.) | ||
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C | ||
Application:
Based on its features, Headsun recommend that this model be applied to Digital Signage, Kiosk, advertising display, industrial machine etc.
