98-1100-1134-7 19.42 Inch 3M surface capacitive Touch Panel
Description:
These touch screens are surface capactive touch screens and the best replacement for 3M touch screen, widely used on marine electronics display screen, especially for Lowrance fishfinder GPS Navigaton Chartplotter to fish hunter.
Parameter：
| 3M Surface Capacitive Screen list | |||||||
| Serial number | Number | Size(inch) | company | top level number | US Number | AA size(mm) | AV size(mm) |
| 124 | 32 | 19.34 | 3M | 17-9251-204 | 98-0003-2206-9 | 390.85*248.44 | 426.97*277.00 |
| 125 | 19.34 | 3M | 17-9251-205 | 98-0003-2716-7 | 390.85*248.44 | 426.97*277.00 | |
| 126 | 19.34 | 3M | 17-9251-206 | 98-0003-2717-5 | 390.85*248.44 | 426.97*277.00 | |
| 127 | 19.34 | 3M | 17-9251-223 | 98-0003-2208-5 | 390.85*248.44 | 426.97*277.00 | |
| 128 | 19.34 | 3M | 17-9251-227 | 98-0003-2720-9 | 390.85*248.44 | 426.97*277.00 | |
| 129 | 19.34 | 3M | 17-9251-220 | 98-0003-2718-3 | 390.85*248.44 | 426.97*277.00 | |
| 130 | 19.34 | 3M | 17-9251-226 | 98-0003-3046-8 | 390.85*248.44 | 426.97*277.00 | |
| 131 | 33 | 19.38 | 3M | 17-9141-206 | 98-0003-2964-3 | 369.60*297.97 | 405.89*328.17 |
| 132 | 34 | 19.83 | 3M | 87-6001-221 | 98-0003-2788-6 | 370.08*298.45 | 402.59*327.66 |
| 133 | 19.83 | 3M | 87-6001-231 | 98-0003-2788-4 | 370.08*298.45 | 402.59*327.66 | |
| 134 | 35 | 19.42 | 3M | 17-8891-204 | 98-0003-2660-7 | 360.32*294.06 | 396.01*324.00 |
| 135 | 19.42 | 3M | 17-8891-223 | 98-0003-2663-1 | 360.32*294.06 | 396.01*324.00 | |
| 136 | 19.42 | 3M | 17-8891-220 | 98-0003-3124-3 | 360.32*294.06 | 396.01*324.00 | |
| 137 | 19.42 | 3M | 17-8891-206 | 98-0003-2201-0 | 360.32*294.06 | 396.01*324.00 | |
| 138 | 19.42 | 3M | 17-8891-205 | 98-0003-2661-5 | 360.32*294.06 | 396.01*324.00 | |
| 139 | 19.42 | 3M | 17-8891-227 | 98-0003-2955-1 | 360.32*294.06 | 396.01*324.00 | |
| 140 | 19.42 | 3M | 17-8891-226 | 98-0003-2664-9 | 360.32*294.06 | 396.01*324.00 | |
| 141 | 36 | 19.42 | 3M | / | 98-1100-1133-9 | 362.98*292.62 | 396.01*324.00 |
| 142 | 19.42 | 3M | / | 98-1100-1134-7 | 362.98*292.62 | 396.01*324.00 | |
| 143 | 37 | 19.71 | 3M | 17-8051-203 | 98-0003-2532-8 | 366.50*297.49 | 402.59*327.66 |
| 144 | 19.71 | 3M | 17-8051-205 | 98-0003-2185-5 | 366.50*297.49 | 402.59*327.66 | |
| 145 | 19.71 | 3M | 17-8051-206 | 98-0003-2186-3 | 366.50*297.49 | 402.59*327.66 | |
| 146 | 19.71 | 3M | 17-8051-221 | 98-0003-2537-7 | 366.50*297.49 | 402.59*327.66 | |
| 147 | 19.71 | 3M | 17-8051-227 | 98-0003-2927-0 | 366.50*297.49 | 402.59*327.66 | |
| 148 | 19.71 | 3M | 17-8051-218 | 98-0003-2535-1 | 366.50*297.49 | 402.59*327.66 | |
| 149 | 19.71 | 3M | 17-8051-226 | 98-0003-3114-4 | 366.50*297.49 | 402.59*327.66 | |
| 150 | 19.71 | 3M | N/A | 98-0003-3535-0 | 366.50*297.49 | 402.59*327.66 | |
| 151 | 19.71 | 3M | N/A | 98-0003-3199-5 | 366.50*297.49 | 402.59*327.66 | |
| 152 | 19.71 | 3M | N/A | 98-0003-3413-0 | 366.50*297.49 | 402.59*327.66 | |
| 153 | 19.71 | 3M | N/A | 98-0003-3421-3 | 366.50*297.49 | 402.59*327.66 | |
| 154 | 19.71 | 3M | N/A | 98-0003-3422-1 | 366.50*297.49 | 402.59*327.66 | |
| 155 | 19.71 | 3M | N/A | 98-0003-3423-9 | 366.50*297.49 | 402.59*327.66 | |
| 156 | 38 | 19.74 | 3M | 17-8551-204 | 98-0003-2622-7 | 366.60*298.27 | 402.69*328.50 |
| 157 | 19.74 | 3M | 17-8551-220 | 98-0003-3163-1 | 366.60*298.27 | 402.69*328.50 | |
| 158 | 19.74 | 3M | 17-8551-223 | 98-0003-2624-3 | 366.60*298.27 | 402.69*328.50 | |
| 159 | 19.74 | 3M | 17-8551-221 | 98-0003-3164-9 | 366.60*298.27 | 402.69*328.50 | |
| 160 | 19.74 | 3M | 17-8551-205 | 98-0003-3260-5 | 366.60*298.27 | 402.69*328.50 | |
| 161 | 19.74 | 3M | 17-8551-226 | 98-0003-3346-2 | 366.60*298.27 | 402.69*328.50 | |
| 162 | 19.74 | 3M | 17-8551-227 | 98-0003-3261-3 | 366.60*298.27 | 402.69*328.50 | |
| 163 | 39 | 19.75 | 3M | 17-8511-203 | 98-0003-2609-4 | 368.02*296.85 | 402.69*328.50 |
| 164 | 19.75 | 3M | 17-8511-221 | 98-0003-2613-6 | 368.02*296.85 | 402.69*328.50 | |
| 165 | 19.75 | 3M | 17-8511-206 | 98-0003-2611-0 | 368.02*296.85 | 402.69*328.50 | |
| 166 | 19.75 | 3M | 17-8511-218 | 98-0003-3156-5 | 368.02*296.85 | 402.69*328.50 | |
| 167 | 19.75 | 3M | 17-8511-205 | 98-0003-2610-2 | 368.02*296.85 | 402.69*328.50 | |
| 168 | 19.75 | 3M | 17-8511-226 | 98-0003-3157-3 | 368.02*296.85 | 402.69*328.50 | |
| 169 | 19.75 | 3M | 17-8511-227 | 98-0003-2615-1 | 368.02*296.85 | 402.69*328.50 | |
Features and Benefits:
3M surface capacitive touchscreen, it usually uses in gaming machine refurbishment.
Revitalize your gaming machines, captivate players, and elevate your gaming establishment's reputation with Head Sun's superior touchscreen solutions. Experience enhanced responsiveness, durability, and performance with every touch, ensuring gamers return for more!
Enhanced Gaming Interaction: Elevate user engagement and experience with our high-quality touchscreens, ensuring smooth gameplay and interactive interfaces.
Durable & Reliable: Built to withstand rigorous gaming environments, our touchscreens guarantee longevity, minimizing downtime, and maximizing profitability.
Seamless Integration: Tailored to fit gaming machines seamlessly, Head Sun's 20.65-inch touchscreens ensure effortless installation and compatibility.
Cost-Efficient Solution: Refurbish gaming machines without hefty investments! Head Sun offers competitive pricing, delivering exceptional value without compromising on quality.
Customized Refurbishments: Beyond touchscreens, explore our comprehensive refurbishment solutions, ensuring your gaming machines look and perform like new.
Package & Shipping:
1.The first step.Touch panels areput on the plastic pallet
2.The second step.Putting each pallet into outer carton with the polyfoam covering on it to protect per CTP
3.The third step.Then putting another pallet into outer carton
4.The 4th step.Sealing and finishing packaging
Detail:
Reference number 98-1100-1134-7, 19.42 inch surface capacitive touch screen.
